POOL COVER PUMPS
92395: POOL COVER PUMP
Thermoplastic Construction
FEATURES
-
2100 GPH @ 0’
-
Thermoplastic construction with built-in handles for ease of transport and installation
-
1” NPT discharge
-
3/4” garden hose adapter
-
Activates in 1-1/2” of water
-
Pumps down to 3/4” of water
-
Large base design for added stability
-
Bottom screen removes easily for cleaning
-
Internal automatic vertical float switch
-
Hermetically sealed, oil cooled motor for long pump life
-
Clog resistant impeller
-
Motor is thermally protected with automatic reset thermal protector
-
Energy efficient split capacitor motor. Lower amp draw, runs cooler, lasts longer
-
Stainless steel motor shaft
-
Carbon/ceramic/stainless steel mechanical shaft seal
-
Upper and lower permanently lubricated ball bearings
-
Stainless steel fasteners
-
Acceptable for indoor or outdoor use
-
Compact, lightweight design is easily portable
-
Every unit is 100% pressure tested
Technical Specifications
MOTOR SPECIFICATIONS | |
HORSEPOWER | 1/3 |
VOLTAGE | 120 |
AMPS | 3.8 |
HERTZ | 60 |
PHASE | Single |
RPM | 3450 |
MOTOR TYPE | Permanent Split Capacitor (PSC) |
INSULATION | Class A |
CIRCUIT REQUIREMENTS | 15 amp (mini) Individual Circuit |
DUTY RATING | Continuous* For continuous operation, the water depth must be at least 1-1/2" to prevent the motor from overheating |
SHAFT SEAL | Carbon/Ceramic and Stainless Steel |
MOTOR SHAFT | Stainless Steel |
UPPER MOTOR BEARING | Ball Bearing |
LOWER MOTOR BEARING | Ball Bearing |
COOLING | Oil Cooled |
MOTOR PROTECTION | Auto Reset Thermal Overload Protection |
PUMP SPECIFICATIONS | |
DISCHARGE SIZE | 1" NPT & 3/4" Garden Hose Thread |
CORD LENGTH | 25’ |
CORD TYPE | SJTW, UL Listed, 3-Wire, 18 Gauge |
PUMP HOUSING | Thermoplastic |
PUMP BASE | Thermoplastic |
IMPELLER MATERIAL | Thermoplastic |
IMPELLER TYPE | Clog Resistant |
GASKET | Bruna-N |
LIQUID TEMP. RANGE | 35° F - 120° F |
OPERATION | Automatic |
FASTENERS | Stainless Steel |
MAX FLOW RATE | 35 Gallons Per Minute |
MAX HEAD | 25’ |
MAX PRESSURE | 10.8 PSI |
WEIGHT | 11 LBS |
WARRANTY | 3 Years |
AUTOMATIC SWITCH SPECIFICATIONS | |
TYPE | Internal SJE Rhombus Vertical Master II |
SWITCH ON POINT | 1-1/2" |
SWITCH OFF POINT | 3/4" |
MATERIAL | High impact PVC |
